The Electro-Voice ZLX-15 Passive Speaker delivers the trusted audio quality of EV components in a versatile, high-performance package. Engineered to exacting standards, this speaker is perfect for larger applications, whether used alone or paired with a subwoofer. Its 15” woofer provides extended low-frequency response, while the 1.5” titanium compression driver ensures clear, intelligible highs. With a frequency range of 44 Hz – 20 kHz and 250 W continuous / 1000 W peak power handling, the ZLX-15 is ready for demanding live sound and portable PA setups.

Designed for wide and even coverage, the speaker offers 90° horizontal by 60° vertical dispersion, a sensitivity of 96 dB SPL, and maximum SPL of 126 dB. The rugged polypropylene enclosure and 18-gauge steel grille with black powder coat protect the speaker while keeping it lightweight and portable at just 36.5 lbs. Dual NL4 connectors make it easy to daisy-chain multiple units for larger setups.

Features

• 15” woofer for deep low-frequency response
• 1.5” titanium high-frequency compression driver
• Frequency response: 44 Hz – 20 kHz
• Power handling: 250 W continuous / 1000 W peak
• Sensitivity: 96 dB SPL, Maximum SPL: 126 dB
• Coverage: 90° horizontal x 60° vertical
• Rugged polypropylene enclosure with 18-gauge steel grille
• Dual NL4 connectors for easy setup
• Lightweight: 36.5 lbs (16.6 kg)

Specs

• Type: Passive Speaker
• LF Transducer: EVS-15L, 15-inch woofer
• HF Transducer: DH-1K titanium compression driver
• Crossover Frequency: 1.7 kHz
• Nominal Impedance: 8 Ω
• Minimum Impedance: 7 Ω
• Connectors: Dual NL4
• Enclosure Material: Polypropylene
• Grille: 18-gauge steel, black powder coat
• Dimensions (H x W x D): 27" x 17" x 15" (685 mm x 423 mm x 383 mm)
• Net Weight: 36.5 lbs (16.6 kg)
• Shipping Weight: 48.3 lbs (22.0 kg)
• Recommended High-Pass Frequency: 40 Hz
• Maximum SPL: 126 dB
• Manufacturer: Electro-Voice
