The Digital Evolution of an Analog Classic

Building on the legacy of Yamaha's MG Series—already established as a global standard in mixing consoles—MGX digital mixing consoles deliver a perfect blend of flexibility, performance, and premium sound quality, excelling in a versatile range of live and installed sound, podcast/live streaming, music production, and recording applications.

In addition to the essential features and versatility you expect from a professional mixer, the MGX12V also integrates an HDMI-USB audio/video interface with capture and pass-through functionality. This enables users not only to mix and output audio in a variety of ways, but also to simultaneously capture video to a PC and record or stream it together with the audio.

For content creators, sound engineers, producers, artists, and streamers—and especially for those producing podcasts with four participants—the four mic inputs and four headphone outputs, together with the ability to seamlessly integrate high-definition video into their workflow, opens up new creative possibilities in a wider range of environments. In any application that involves content with both audio and video, the MGX12V will elevate your production quality and captivate your audience.

Features

• 11 + 1 fader configuration (non-motorized fader)
• A 4.3-inch touchscreen with five control knobs
• Input mixing channels: 4 mono + 4 stereo + 1 Sound Pad + 2 FX return
• Busses: 1 STEREO + 8 MIX
• Local Inputs: 4 Combo (Mic/Line), 4 TRS (Line), 4 RCA (Line)
• Local Outputs: 2 XLR, 6 TRS Phone, 4 Headphones
• USB MAIN: 18 inputs / 18 outputs (32-bit / 96 kHz)
• USB SUB: 2 inputs / 2 outputs (16-bit / 48 kHz)
• microSD Card: 16-track recording / 2-track playback (24-bit / Up to 96 kHz)
• Bluetooth Audio Input: 2 inputs (Bluetooth 5.0, A2DP)
• HDMI-to-USB video/audio input with capture function and real-time HDMI passthrough
• Built-in DSP processor for professional sound and latency-free monitoring
• Assistive features: Auto Gain, Clip Safe, Simple / Standard mode, Scene Recall
• Included accessories: Start Guide, Safety Guide, Steinberg Software License Card x2 (Cubase AI + WaveLab Cast, Steinberg Plus), Basic FX Suite license card, AC Power Adapter (PA-300C)

Specs

Analog Input	4 Combo, 4 TRS, 4 RCA
Analog Output	2 XLR, 6 TRS
USB TO HOST	2 (Type-C)
Phones	4 TRS
Bluetooth	Ver 5.0 (A2DP)
HDMI	1 IN / 1 THRU (Audio/Video input/capture/pass-through)
Storage Slots	microSD Slot
Screen / Controls	4.3" Touch Screen
Faders / Knobs	12 Faders/Knobs
USB (Main)	18-track
microSD Card	16-track Rec
Sampling Rate	96 kHz - 44.1 kHz
Signal Delay	< 0.4 ms
Dynamic Range	125 dB typ.
Input Channels	4 mono + 4 stereo
Mix Buses	8 (mono)
DSP FX	Gate, Comp, EQ, REV-X, etc.
Dimensions (WxHxD)	335 x 96 x 319 mm
Net Weight	4.1 kg
Power Consumption	38.4 W
